| Product features |
| ✮Stable 4G connection |
| ✮Remote active wake-up, two-way voice intercom |
| ✮Quick start, start recording within 400ms |
| ✮Intelligent detection of human movement, intelligent alarm push |
| ✮8000mAh battery powered, low battery reminder |
| ✮Low power system optimization |
| ✮1-day free cloud storage to save alarm videos |
| ✮Dual lens dual recording to guard different directions |
| ✮Dual lens linkage, automatic zoom |
| ✮Dual light source, full color day and night |
| ✮Low power and corded power compatible design |
| Sorts |
Type |
Parameters |
| System |
Operating system |
Linux |
| Online visitor |
Supports 4 visitors at the same time |
| APP |
O-KAM |
| Collection |
CPU |
T40N |
| Internal storage |
1GB |
| Image sensor |
GC2083+GC2083 |
| Minimum illumination |
0.8Lux/F1.４(color mode), 0.3Lux/F1.4(B&W mode) |
| Lens |
Bullet camera: focal length 4mm, 1G3P Dome camera: focal length 4mm, 1G3P |
| Sensor performance |
Support automatic white balance, automatic gain control and automatic backlight compensation |
| PTZ |
Horizontal 305°, vertical 90° |
| Viewing angle |
Bullet camera：100° diagonal, dome camera：60° diagonal |
| Video |
Night vision |
Full color night vision, dual light source, 6 infrared lights+6 white lights |
| Compression standard |
H.264 /MJPEF/JPEG |
| Multi stream |
Main stream: 1080P/15fps, sub stream:360P/15fps |
| IR control |
When the IR night vision function is enabled, IR and ICR are automatically detected; when the IR night vision function is disabled, IR is off and ICR is fixed in the day vision mode. |
| Bit rate |
CBR/VBR two rate control modes, and the output rate range is 128~4096kbps |
| Image adjustment |
Vertical, horizontal adjustable, OSD display |
| Audio |
Input |
Built-in-38dB microphone |
| Output |
Built-in 8Ω1W speaker |
| Sampling frequency/bit width |
8KHz/16bit |
| Compression standard/Bit Rate |
G711A |
| AI |
Humanoid detection |
Humanoid detection, filtering invalid video content |
| Area detection |
Free daub, only monitoring the areas concerned by users |
| Smart notification sound |
Different devices push different sounds, so that you can know exactly which device is triggered |
| Intelligent alarm sound |
Set different equipment alarm sounds according to different scenarios |
| More AI functions (testing) |
Pets, vehicles, parcels, etc |
| Network |
Networking |
Use APP to scan the QR code on device to add; Use the device to scan QR code on APP to add |
| Cat1 China |
FDD:B1/B3/B5/B8 TDD:B34/B38/B39/B40/B41 |
| Cat4 Overseas |
European/Japanese/US versions |
| Key/interface |
Key 1 |
On/Off key |
| Reset key |
long press to restore factory settings |
| Storage |
External TF card |
Support TF card (up to 256GB) |
| Cloud storage |
One-day free loop cloud storage |
| Alarm |
Sound light alarm |
Sound light alarm，6 infrared lights+6 white lights, full color night vision |
| Alarm detection |
Support for human detection, PIR infrared human detection for 10 meters |
| Physical Indicators |
Rated voltage |
DC5V±5% |
| Power supply |
Equipped with 8000mAh battery |
| Consumption |
Sleep standby 300uA，working：400MA-1.5A max |
| Operating condition |
Temperature: -10～55℃; Humidity: ＜90% |
| Weight |
Net weight: 770g; Gross weight: 1680g |
| Size |
Camera：210*115*206mm |
| Packing list |
Camera * 1, manual * 1, solar panel * 1, solar panel bracket * 1 |
